Netapp NS0-191 - NetApp Certified Support Engineer (NCSE) Exam Exam

Page:    1 / 12
Total 60 questions

A customer has replaced both interconnect cables on a FAS3240 HA pair with IOXM because they were damaged. After replacing the cables, the customer receives the error shown below.
HA interconnect port 1 of this appliance seems to be connected to port 2 on the partner appliance.
In this scenario what is the cause of this error?

  • A. The interconnect cables must not be replaced while the controllers are up and running.
  • B. c0a and c0b are 10Gbit Ethernet ports which must not be used for the interconnect.
  • C. The interconnects are cross-cabled, you must connect c0awith c0a and cob with c0b.
  • D. You must issue theifconfig down command followed by theifconfig up command for both ports, on both controllers, after replacing the cables.


Answer : C

Explanation: References:

When troubleshooting the delivery failure of an AutoSupport notification, you enter the autosupport history show command.
In this scenario, what information would you expect the command output to show? (Choose two.)

  • A. time of the last upgrade
  • B. status of the delivery
  • C. size of the AutoSupport notification
  • D. IP address of the destination


Answer : B,D

Explanation: References:

Your customer using clustered Data ONTAP 8.1.2 recently had a disk drive fail. They already swapped out the failed disk for a replacement disk. They call you the next day explaining that the disk is not showing up in the spare disk pool.
In this scenario, what are two reasons for this problem? (Choose two.)

  • A. The replacement disk drive needs to be manually un-failed before the disk will show up as a spare.
  • B. Autoassignis turned off, leaving the disk unassigned; the customer needs to take ownership of the replaced disk before it will show up as a spare disk.
  • C. The disk ID needs to be removed from the failed disk registry before the disk will be seen as a spare.
  • D. Autoassign is set to on, but the disk shelves in the loop are shared between a high- availability (HA) pair, causing the disk to show up as unassigned.


Answer : B,C

You are preparing to implement a storage virtual machine (SVM) in a SAN configuration.
You need to eliminate single points of failure and enable the system to survive component failures.
According to NetApp, what is the recommended minimum number of paths per LUN connecting to each node being used by an SVM in a cluster?

  • A. 4
  • B. 2
  • C. 1
  • D. 3


Answer : B

Explanation: References:

A customer observes write latencies above 40 ms on a clustered Data ONTAP system with two FAS3220s for a period of several minutes each night. During performance analysis, you discover that several back-to-back Cps occur.
In this scenario, which two configuration changes will reduce the write latencies? (Choose two.)

  • A. Move the volume with the highest write load to an aggregate with faster disks.
  • B. Migrate the LIF with the highest network receive rate to a faster port.
  • C. Add more disks to the aggregate.
  • D. Add flash cache cards to the nodes.


Answer : A,D
