Cisco 500-171 - Implementing and Administering the FlexPod Solution (FPIMPADM) Exam

Page:    1 / 10
Total 50 questions

Which three are true for UCS 2208XP? (Choose three)

  • A. Works with FI 6120 and FI 6296
  • B. Supports FCoE
  • C. Supports native FC
  • D. Has 32 10Gb ports to each half-width slot in the chassis
  • E. Supports 4 port port-channel toward FI 6140
  • F. Connects to both Fabric Interconnects for high availability


Answer : ABD

Which two are required for single-wire management for Cisco UCS C-Series? (Choose two)

  • A. UCS Manager 2.1 or higher
  • B. VIC 1240
  • C. Redundant Nexus 2232PP FEX
  • D. 10 GB LOM
  • E. FI 6200 family only
  • F. VIC 1225


Answer : AF

Which policy detail should be set if you want a server to be exempt from all power capping?

  • A. Create a Power Control Policy and set Power Capping to No Cap
  • B. Create a Power Control Policy select cap and set the priority to 1
  • C. Create a Power Group with the appropriate chassis and set the Group Budget Power Cap (W) to 0.
  • D. The UCS Power Cap feature should not be utilized in a FlexPod environment.


Answer : A

Which two are correct about VSAN configuration within UCS Manager? (Choose two)

  • A. VSAN ID and FCoE VLAN ID have to match
  • B. VSAN can be configured as fabric interconnect specific
  • C. We can delete VSAN 1
  • D. VSAN IDs 3840-4079 are not available regardless of the Fabric Interconnect mode
  • E. VSAN can be configured as a global parameter
  • F. In addition to SAN tab, VSANs can be configured under UCSM Server tab as well


Answer : BE

Which two are true about Fabric Interconnect L1 and L2 ports in cluster mode? (Choose two)

  • A. Fabric Interconnects connected via L1/L2 have to be the same model except during the upgrade
  • B. Ports are primarily used for management traffic, but can be used for data traffic as well
  • C. Fabric Interconnect ports L1 and L2 are 10 Gb links
  • D. Ports can only run as a port channel
  • E. Ports can only run as individual links
  • F. Ports can run as a port channel or as individual links


Answer : AD
